The Mk VI Rollo-Mixer® Batch Mixer

The Mk VI is a globally used batch mixer designed to uniformly blend and evenly coat powders/dry particulates. The Mk VI provides powder blending and coating accuracy in numerous industrial batch mixing, blending and coating applications. The open turbine section offers different loading, access, and venting options.

The Mk VI design is ideal for: Animal Health Products, Calf Milk Replacer, Animal Feed with Molasses, Trace Mineral Pre-Mixes, Specialty Polymers, Treating Powders, Industrial Cleaners, Insulation Products, Coating Kaolin Clays, and Magnesium Oxide Powders


  • Built with award-winning liquid addition Free-Fall Processing®
  • Known for its proven quality, efficiency and reliability
  • Operates with over 25 divisions per revolution
  • Results in uniform batch mixing & blending in minutes
  • Available in 51 sizes from 3.5 to 1,286 cu ft
  • MK VI Features and Accessories


The Mk VI Rollo-Mixer® can be loaded from chutes and hoppers above and on the side of the mixer. The batch mixer is full at shaft center and multiple ingredients can be loaded while it is at rest or in motion. The Rollo-Mixer batch-mixer machine can accommodate multiple methods of loading by gravity from silos, super saks, Gaylord bags, and pneumatically from elevator legs, bags and boxes.


While the batch mixer operates, the product is being blended throughout the discharge. Material from the free-falling curtain is diverted out the discharge chute in a steady, unimpeded, uniform stream. Depending on the speed and size of the batch mixer, the product can be discharged up to 2 tons per minute. The Rollo-Mixer® continues running until product discharge is complete.

Additional Information

Materials of Construction Finishes Available
(material contact points)

  • Carbon Steel – High Release Finish
  • 304 L Stainless Steel
  • 80 or 150 grit Polished finish
  • Abrasion Resistant Plate

Safety & Maintenance

  • State of the art safety switches
  • Painted Carbon or Stainless Steel Guarding
  • Accessible Zirk fittings
  • Automatic chain oiler


  • CE
  • CSA
  • NEMA 12,
  • NEMA 4x
  • Class II, Div. 1 & 2

Mk VI Series & Sizes

Available in 51 sizes from 3.5 to 1,286 cu ft.  Contact us for dimensional specifications.

View All Load Volumes

  • 28 Series (3.5 ft³, 5 ft)
  • 31 Series (10 ft³, 15 ft³)
  • 50 Series (25 ft³ – 40 ft³)
  • 62 Series (40 ft³ – 83 ft³)
  • 74 Series (75 ft³ – 172 ft³)
  • 86 Series (133 ft³ – 267 ft³)
  • 98 Series (200 ft³ – 400 ft³)
  • 101 Series (343 ft³ – 629 ft³)
  • 120 Series (533 ft³ – 1000 ft³)
  • 132 Series (833 ft³ – 1286 ft³)

Load Volume Calculator

Batch Size (lbs/batch) ÷
Product Density (lbs/cu ft) =
Load Volumne (cu ft)
Batch Size (kg/batch) ÷
Product Density (kg/cu ft) =
Load Volumne (cu ft)
Determine which Rollo-Mixer® best fits your needs: View Product Specs

Test Your Product

We invite you to our test facility in Wisconsin to run trials with the 10 cu ft Mk VI Rollo-Mixer®. Watch your products be uniformly blended, or treated with liquids in multiple ways exclusively through “Free-Fall Processing”®
